SHE600 Rotary electrical filling system is the new type of machine we developed base on Germany technology. It suitable for various type cans (two-piece can, three-piece can) filling and seaming, the maximum capacity can reach 40000CPH at high speed running conditions. Its technical parameters are at the leading level in domestic similar products, which can be comparable to imported equipment.

No.	Item	Parameter
1	Capacity	600CPM (based on 330ml can)
2	Filling valve	60
3	Seaming head	8
4	Filling temperature	2-4℃
5	Filling method	Pressure equalization
6	Exhaust oxygen device	CO2 automatic purge of displacement
7	Distance between filling valves	117.8mm
8	Beer bowl up, down regulation system	electric
9	Filling level accuracy	±2mm
10	Working type	Filler driving force from seamer
11	Inlet and outlet of can direction	360 degrees
12	Total power	11KW
13	Motor Brand	SEW
14	PLC	Siemens
15	Inverter	DANFOSS
16	Bearing brand	SKF or NSK
17	Overall Size (L*W*H)	6500*2607*2170mm
