The rotary counter pressure filler-seamer system is suitable for beer & carbonated drink can filling and seaming. The technology of filling valve and control system adopt original technology of Germany, while seaming technology is that of Switzerland. The machine adopts advanced mechanical, electrical and pneumatic control technology. Features: working stable, accurate filling level, attractive appearance, low O2 pickup, low liquid lost and convenient maintenance.

No.	Item	Parameter
1	Capacity	100CPM (based on 330ml can）
2	Filling valve	10
3	Seaming head	2
4	Filling temperature	2-4℃
5	Filling method	Counter pressure
6	Exhaust oxygen device	CO2 automatic purge of displacement
7	Distance between filling valves	200mm
8	Beer bowl up, down regulation system	manual
9	Filling level accuracy	±2mm
10	Working type	Filler driving force from seamer
11	Inlet and outlet of can direction	180 degrees
12	Total power	5KW
13	PLC	Siemens
14	Inverter	DANFOSS
15	Bearing brand	SKF or NSK
16	Overall Size (L*W*H)	2855*1780*2235mm
